Mobile module
|
4G (LTE) – Cat 4 up to 150 Mbps, 3G – Up to 42 Mbps, 2G – Up to 236.8 kbps.
|
|
Status
|
Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP Bytes sent/received
|
|
SMS
|
SMS status, SMS configuration, send/read SMS via HTTP POST/GET, EMAIL to SMS (optional), SMS to EMAIL(optional), SMS to HTTP (optional), SMS to SMS (optional), scheduled SMS, SMS autoreply, SMPP (optional)
|
|
Black/White list
|
Black/White list
|
|
Multiple PDN (optional)
|
Possibility to use different PDNs for multiple network access and services
|
|
WIRELESS
|
|
Wireless mode
|
IEEE 802.11b/g/n, Access Point (AP), Station (STA)
|
|
WiFi
|
WPA2-Enterprise (with external/internal Radius server), WPA2-PSK, WPA-PSK, WEP, MAC Filter
|
|
WiFi security
|
WPA2-Enterprise - PEAP, TLS, TTLS, AES-CCMP, TKIP, Auto Cipher modes, Client separation
|
|
SSID
|
SSID stealth mode and access control based on MAC address
|
|
WiFi users
|
up to 80 simultaneous connections
|
|
Hotspot
|
Captive portal (Hotspot), internal/external Radius server , built in customizable landing page
|
|
NETWORK
|
|
Routing
|
Static routing, Dynamic routing (Optional - BGP, OSPF v2, RIP v1/v2)
|
|
Network protocols
|
TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SMTP, SSL v3, TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, MQTT (optional) SMPP, MQTT
|
|
Connection monitoring
|
Ping Reboot, Periodic Reboot, LCP and ICMP for link inspection
|
|
Firewall
|
Port forward, traffic rules, custom rules
|
|
DHCP
|
Static and dynamic IP allocation
|
|
QoS
|
Traffic priority queuing by source/destination, service, protocol or port
|
|
DDNS
|
Supported >25 service providers, others can be configured manually
|
|
Network backup
|
Mobile and WiFi WAN options, each of which can be used as backup
|
|
Load balancing (optional)
|
Balance your internet traffic over multiple WAN connections
|
|
NetSnapper (optional)
|
Mobile connection management, data compression VPN client (not available in standard FW)
|
|
SSHFS (optional)
|
Possibility to mount remote file system via SSH protocol (not available in standard FW)
|
|
SECURITY
|
|
Authetication
|
Pre-shared key, digital certificates, X.509 certificates
|
|
Firewall
|
Pre-configured firewall rules can be enabled via web-ui, unlimited firewall configuration via CLI; DMZ; NAT; NAT-T
|
|
Attack prevention
|
DDOS prevention (SYN flood protection, SSH attack prevention, HTTP/HTTPS attack prevention), port scan prevention ( SYN-FIN, SYN-RST, X-mas, NULL flags, FIN scan attacks)
|
|
WiFi security
|
WPA2-Enterprise – PEAP, EAP-TLS, TLS, TTLS. AES-CCMP, TKIP, Auto Cipher modes. Client separation
|
|
Mobile quota control
|
Set up custom data limits for the SIM card
|
|
WEB filter
|
Blacklist for blocking out unwanted websites, whitelist for specifying allowed sites only
|
|
Access control
|
Flexible access control of TCP, UDP, ICMP packets, MAC address filter
|
|
VPN
|
|
OpenVPN
|
Multiple clients and server can be running simultaneously, 12 encryption methods
|
|
OpenVPN Encryption
|
DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, BF-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC, AES-192-CBC, AES-256-CBC
|
|
IPsec (optional)
|
IKEv1, IKEv2, supports up to 4x VPN IPsec tunnels (instances), with 5 encryption methods (DES, 3DES, AES128, AES192, AES256)
|
|
GRE (optional)
|
GRE tunnel
|
|
PPTP, L2TP (optional)
|
Client/Server services can run simultaneously
|
|
MONITORING & MANAGEMENT
|
|
WEB UI
|
HTTP/HTTPS, status, configuration, FW update, CLI ,troubleshoot, event log, system log, kernel log
|
|
FOTA
|
Firmware update from sever, automatic notification.
|
|
SSH
|
SSH (v1, v2)
|
|
SMS
|
SMS status, SMS configuration, send/read SMS via HTTP POST/GET
|
|
TR-069
|
OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly tech, AVsystems
|
|
MQTT (optional)
|
MQTT Broker, MQTT publisher
|
|
SNMP (optional)
|
SNMP (v1, v2, v3), SNMP trap
|
|
JSON-RPC
|
Management API over HTTP/HTTPS
|
|
RMS
|
Teltonika Remote Management System (RMS)
|
|
SYSTEM CHARACTERISTICS
|
|
CPU
|
Atheros Hornet, MIPS 74Kc, 550MHz
|
|
RAM
|
64MB, DDR2
|
|
FLASH memory
|
16MB SPI Flash
|
|
FIRMWARE / CONFIGURATION
|
|
WEB UI
|
Update FW from file, check FW on server, configuration profiles, configuration backup, restore point
|
|
FOTA
|
Update FW/configuration from server
|
|
RMS
|
Update FW/configuration for multiple devices
|
|
Keep settings
|
Update FW without losing current configuration
|
|
FIRMWARE CUSTOMIZATION
|
|
Operating system
|
RutOS powered by Linux based on OpenWRT
|
|
Supported languages
|
Busybox shell, Lua, C, C++
|
|
Development tools
|
GPL package with built environment provided
|
|
LOCATION TRACKING
|
|
GNSS
|
GPS, GLONASS, BeiDou, Galileo and QZSS
|
|
Coordinates
|
GNSS coordinates via WebUI, SMS, TAVL, RMS
|
|
NMEA
|
NMEA 0183
|
|
Server software
|
supported server software TAVL, RMS
|
|
Mobile Network Geolocation
|
Location without using GPS, get approximate location based on mobile tower on RMS
|
|
Startup
|
Hot start <2.5s, Warm start <26s, Cold start <35s
|
|
Tracking
|
55 simultaneous satellites channels
|
|
Sensitivity
|
-157 dBM
|
|
Accuracy
|
< 1.5m
|
|
POWER
|
|
Connector
|
4 pin DC power socket
|
|
Input voltage range
|
9 – 30 VDC (4 pin industrial socket), reverse polarity protection, overvoltage protection up to 60VDC, surge protection >66VDC 10us max.
|
|
Power consumption
|
< 5W
|
|
PHYSICAL INTERFACES (PORTS, LEDS, ANTENNAS, BUTTONS, SIM)
|
|
Status LEDs
|
3 x connection type status LEDs, 1 x r WiFi status LED, 5 x connection strength LEDs, 1 x Power LED
|
|
SIM
|
1 x SIM slots (Mini SIM – 2FF, 2st form factor), 1.8V/3V, external SIM holder
|
|
Power
|
4 pin DC connector
|
|
Anntenas
|
2 x RG174 connectors for LTE
|
|
Reset
|
Reset/restore to default button
|
|
PHYSICAL SPECIFICATION
|
|
Casing material
|
Plastic housing, plastic panels
|
|
Dimensions
|
131 mm x 79 mm x 18 mm (H x W x D)
|
|
Weight
|
115 g
|
|
OPERATING ENVIRONMENT
|
|
Operating temperature
|
-40 °C to 75 °C
|
|
Operating humidity
|
10% to 90% non-condensing
|
|
Ingress Protection Rating
|
IP30
|
|
MTBF
|
290000 h
|
